电梯型号 Type |
电梯载重量 load (Kg) |
电梯速度 speed (m/s) |
电梯轿厢规格 Car specifications(A*B) |
电梯开门尺寸 Open the door size (Pl*LH) |
电梯井道尺寸 Shaft size (C*D) |
电梯底坑深度 Pit depth (P) |
电梯顶层高度 Overhead height(Q) |
自动门(旁开) Automatic Door (Side Open) |
320 | 0.4 | 850*1000 | 700*2100 | 1400*1400 | ≥180 | ≥2950 |
≥350 | ≥2750 | ||||||
320 | 0.4 | 950*1100 | 800*2100 | 1500*1500 | ≥180 | ≥2950 | |
≥350 | ≥2750 | ||||||
自动门(中分) Automatic door(middle) |
320 | 0.4 | 850*1000 | 700*2100 | 1500*1350 | ≥180 | ≥2950 |
≥350 | ≥2750 | ||||||
320 | 0.3 | 950*1100 | 800*2100 | 1700*1450 | ≥180 | ≥2950 | |
≥350 | ≥2750 | ||||||
自动门(中分双折) Automatic door (middle double fold) |
320 | 0.4 | 850*1000 | 750*2100 | 1400*1400 | ≥180 | ≥2950 |
≥350 | ≥2750 | ||||||
320 | 0.4 | 950*1100 | 800*2100 | 1500*1500 | ≥180 | ≥2950 | |
≥350 | ≥2750 | ||||||
手动门 Manual door |
320 | 0.4 | 850*1000 | 800*2100 | 1400*1100 | ≥180 | ≥2950 |
≥350 | ≥2750 | ||||||
320 | 0.3 | 950*1100 | 900*2100 | 1500*1200 | ≥180 | ≥2950 | |
≥350 | ≥2750 |
